Lighting designers in search of a powerful LED PAR wash light will be impressed with the CHAUVET DJ SlimPAR Pro Q USB, a high-powered RGBA (red, green, blue, amber) LED PAR fixture designed to produce a broad spectrum of amber-infused color washes with natural-looking color temperatures. Featuring twelve, 6W (4-in-1) quad-color LEDs that have a beam angle of 16° and a field angle of 31°, it provides wide washes for venue uplighting and heat-free illumination to performers on stage.
The unit can also be wirelessly controlled via the IRC-6 remote (available separately). Easy to operate, the SlimPAR Pro Q USB offers a standalone mode with automated programs such as Sound-Active, RGBA Dimmer, Strobe, and DMX modes for in-depth control. Other features include flicker-free operation (for video applications) and an autosensing power supply. The low-profile SlimPAR Pro Q USB comes equipped with a dual-yoke bracket that can be used for conventional mounting to a truss or lighting stand, or to create a variable-angle floor stand. The fixture ships with a gel-frame holder and gel frame.
Key Features
12 x 6W quad-color RGBA + UV LEDs (red, green, blue, amber) for high-power color washes
Generates a broad spectrum of colors and achieves natural-looking color temperatures with vibrant amber hues
USB port lets you plug the D-Fi USB transceiver (available separately), for wireless Master/Slave or DMX control
Low-profile design easily fits inside most trussing
16° beam angle, 31° field angle
3 DMX channel modes (4, 5, or 10)
Achieve smooth LED fading with built-in dimming curves
Color macros
Built-in automated programs, sound-activated
LED strobe effect
Standalone or Master/Slave configuration
Flicker-free operation suitable for on-camera use
Ideal for quiet applications due to silent operation and no moving parts
Daisy-chain power for up to 7 units at 120V, or 13 units at 230V
Multi-voltage operation: 100-240 VAC, auto-ranging
LED display with 4-button menu for easy navigation
Compatible with IRC-6 wireless remote
Double-bracket yoke can be used for conventional mounting or as a variable-angle floor stand
Compatible with most 7.5" barn doors (available separately) for added light control
Includes a gel-frame holder and gel frameLight
Light Type PAR
Light Source 12 x Color LED - 6 W / 2 A
Light Source Life Expectancy 50,000 Hours
Colors Red
Green
Blue
Amber
Photometrics 528.6 fc / 5690 Lux at 6.6' / 2 m
528.6 fc / 5690 Lux at 16.4' / 5 m
Beam Angle 16°
Field Angle 31°
Shutter / Strobe Electronic
Dimming Electronic, 0 to 100%Performance
Operating Modes DMX, Primary/Secondary, Sound-Active, Standalone
Macros / Programs Auto-Program
Color Macro
Effects Strobe (Variable Speed)
Strobe Rate 0 to 31 Hz
Gobos None
PWM Frequency 1.2 kHzControl
Control Protocols DMX512
DMX Channel Modes 3 Mode(s):
4 / 5 / 10-Channel
Display / Controls LED / 4-Button
Remote Control D-Fi USB (with Optional Equipment)
IR Remote (with Optional Equipment)Connectivity
Inputs/Outputs 1 x XLR 3-Pin DMX Input
1 x XLR 3-Pin DMX Output
1 x USB Type-A Remote InputPower
AC Input Power 100 to 240 VAC, 50/60 Hz
AC Power Connector Input: 1 x powerCON
Output: 1 x powerCON
Fuse F 2 A 250 V
Power / Current Consumption 120 VAC, 60 Hz: 82 W / 1 A
230 VAC, 50 Hz: 78 W / 0.6 A
Power Linking 7 Units at 120 VAC
13 Units at 230 VAC
Total Current: 8 AEnvironmental
IP Rating None
Operating Temperature 104°F / 40°CPhysical
Mounting Dual/Scissor Yoke
Duty Cycle None
Exterior Color Black
Max Housing Temperature 104°F / 40°C
Cooling Convection
Certifications CE, MET
*as per Manufacturer
Dimensions 10 x 3.9 x 11.4" / 253 x 98 x 290 mm
Weight 7.2 lb / 3.3 kg
