Midas HUB4 PRO Monitor System Hub with 4 PoE Ports for Personal Mixers or Compatible Stage Boxes 96k Monitor System Hub with 4 PoE Ports

Personal Monitoring with DP48
HUB4 PRO can supply up to four DP48 personal monitor mixers with PoE (Power over Ethernet) and 48 channels of 24-bit/48 kHz audio or 2x 24 channels at 96 kHz. HUB4 PRO also collects 48 channels of upstream audio and forwards this audio to the FOH console, either from stage boxes connected to the AES50-B (THRU) Port or 8 return channels from each of Ports 1-4.

Cascading Hubs for Large Setups
To meet the challenges of large monitoring setups, HUB4 PRO can easily be daisy-chained to make additional DP48 ports available, all the way up to symphonic orchestra applications.
On the other hand, HUB4 PRO can also address situations where you want to connect additional I/O via the same AES50 link to the mixing console. To help build out this AES50 console link, digital stage boxes such as the Midas DL16 or DL32 can be connected to the HUB4’s AES50 (THRU) Port. The console can pass downstream signals to their respective stage outputs, while also receiving 48 channels upstream from the stage inputs via HUB4 PRO

Specifications

Digital Input/Output
AES50
2 x Ethercon™

Hubs
4 x Ethercon™

StageCONNECT
1 x 3 pin XLRM

Analog Outputs
Outputs 1
2 x 6.35 mm TRS jack
2 x 3 pin XLRM

Outputs 2
2 x 6.35 mm TRS jack
2 x 3 pin XLRM

Outputs 3
4 x 6.35 mm TRS jack

Outputs 4
4 x 6.35 mm TRS jack

Output Impedance
100 Ω

Maximum output level
+21.5 dBu

USB
Class compliant USB 2.0 Type B

Controls
Buttons
Port 1 – 4 to AES50 In
StageCONNECT to AES50 In / Update
Port 1 to Outputs 1 / 48 KHz
Port 2 to Outputs 2 / 96 kHz x 2
Port 3 to Outputs 3 / 96 kHz x 1
Port 4 to Outputs 4
Power on/off

LED Indicators
96 kHz
24 Channel
Power On.

Dimensions

Dimensions
48 x 29 x 4.8 cm
Weight
3.96 kg
