Lighting designers and mobile entertainers in search of an LED wash light with brilliant eye-candy effects should check out the Chauvet DJ SlimBANK Q18 ILS, a versatile quad-color (RGBA) LED wash light that easily generates complex looks from the internal auto programs with sectional control. Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types.
Control options include D-Fi USB compatibility for wireless Master/Slave or DMX control and access to built-in automated programs via IRC-6 remote. The fixture includes barn doors, which help direct and focus the light, while selectable dimming modes ensure smooth fading. The SlimBANK Q18 ILS is ideal for sound sensitive environments due to the radiant cooling design.
Versatile quad-color LED wash light with brilliant eye candy effects
Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types
Control any ILS-enabled fixture wired or wirelessly (sold separately)
D-Fi USB compatibility for wireless master/slave or DMX control
Generate complex looks easily with built-in eye-catching auto programs with sectional control
Adjustable barn doors help direct and focus the light
Access built-in automated programs via IRC-6 remote, master/slave, or DMX
Achieve smooth LED fading with built-in dimming curves
Ideal for sound-sensitive environments due to the radiant cooling design
Save time running extension cords by power linking multiple unitsLight
Light Type LED Panel / Special Design / Wash Light
Light Source 18 x Color LED - 4 W / 1 A
Light Source Life Expectancy 50,000 Hours
Colors Red
Green
Blue
Amber
Pixel Configuration 3 x Zones
Photometrics 432.4 fc / 4654 Lux at 6.6' / 2 m
Beam Angle 17°
Field Angle 31°
Shutter / Strobe Electronic
Zoom Adjustment None
Dimming 0 to 100% with 3 Dimmer Modes
Operating Modes Automatic, Color Change, DMX, Primary/Secondary, Program, Sound-Active, Static Color
Macros / Programs 14 x Auto-Program
Effects Blinder
Color Strobe
Strobe Rate 0 to 20 Hz
Gobos None
Control
Control Protocols DMX512
DMX Channel Modes 4 / 6 / 10 / 16-Channel
Display / Controls LED / 4-Button
Remote Control IR Remote (with Optional Equipment)
Connectivity
Inputs/Outputs 2 x XLR 3-Pin DMX Input/Output
AC Input Power 100 to 240 VAC, 50/60 Hz
AC Power Connector Input: 1 x IEC
Output: 1 x Edison
Plug Type: NEMA 5-15
Power / Current Consumption 120 VAC, 60 Hz: 65 W / 0.9 A
230 VAC, 50 Hz: 64 W / 0.5 A
Power Linking 9 Units at 120 VAC
15 Units at 230 VAC
Environmental
IP Rating None
Physical
Mounting Dual/Scissor Yoke
Included Accessories 4 x Barn Doors
1 x Power Cable
Duty Cycle None
Exterior Color Black
Cooling Convection
Certifications CE, RoHS,
*as per Manufacturer
Dimensions 14 x 8.2 x 2.2" / 35.6 x 20.8 x 5.6 cm
Weight 6 lb / 2.7 kg
Packaging Info
Package Weight 9.65 lb
Box Dimensions (LxWxH) 19.3 x 13.7 x 10.7"
