ADAM Audio A7X 7

ADAM AUDIO A7X
The A7X is ADAM Audio’s best selling nearfield monitor. It is one of the most balanced and versatile speakers currently on the market. The X-ART tweeter produces detailed, uncompressed highs and upper mids without being tiring over long listening periods. Despite its compact housing, the bass response is powerful and precise.
The tweeter is driven by a 50 Watt A/B amplifier and the bass/mid-woofer by a 100 Watt PWM amplifier. This achieves a very clean and nuanced reproduction of the midrange frequencies with a seamless transition in the crossover from the 7″ woofer, which operates in the range of 42 Hz to 2.5 kHz, towards the X-ART tweeter.
The A7X‘s ability to exactly reproduce every sonic detail no matter how small, its translucent sound image, tonal depth and stereo localization inspires music producers and explains why it is by far the most reviewed and award-winning monitor in recent years.
STATE OF THE ART TECHNOLOGY
ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.
In the Box:
Adam Professional Audio A7X 7" 150W Active 2-Way Studio Monitor (Single)
Power Cable
Not in the Box
Microphone and Signal Cables

Specifications

WOOFER
Number: 1

Basket Ø: 7" (175 mm)

Voice Coil Ø: 1.5" (38 mm)

Cone Material: Carbon / Rohacell / Glass Fiber

TWEETER
Number: 1

Type: X-ART

Diaphragm Area: 4 inch² (2420 mm²)

Equiv. Diaphragm Ø: 2" (56 mm)

Velocity Transform Ratio: 4:1

Diaphragm Weight: 0.17 g

BUILT-IN AMPLIFIERS
Woofer: 1

Type: PWM

Amp. Power RMS / Music: 100 W / 150 W

Tweeter: 1

Type: A/B

Amp. Power RMS / Music: 50 W / 75 W

CONTROL OPTIONS
Input Sensitivity: -∞ to +14 dB

High Shelf EQ: > 5 kHz ±6 dB

Low Shelf EQ: 300 Hz ±6 dB

Tweeter Gain: ±4 dB

INPUT CONNECTORS
Analog: XLR / RCA

GENERAL DATA
Frequency Response: 42 Hz - 50 kHz (-10 dB)

THD: 90 dB / 1 m > 100 Hz ≤0.5 %

Max. SPL with sine wave acoustic: 100 Hz to 3 kHz at 1 m ≥106 dB

Max. SPL per pair: at 1 m ≥114 dB

Crossover Frequencies: 2.5 kHz

Input Impedance: 30 kOhm

Panel: Front

Weight: 20.3 lb (9,2 kg)

Magnetically Shielded: No

Height x Width x Depth: 13.5" (337 mm) x 8" (201 mm) x 11" (280 mm)

Delivery contents: Power cord, manual

ADAM Audio A7X 7" 150W Active 2-Way Studio Monitor (Single)
