ADAM Audio A8X 8.5

ADAM AUDIO A8X
The A8X adds to the AX-Series as a unique model because its power and radiation characteristics allow it to be used as both a nearfield and midfield monitor. It represents a particularly attractive entry-level model for midfield monitoring which offers transparent reproduction of higher frequencies, clear mids and an excellent transient response.
The extra large, front-positioned bass reflex ports are perfectly matched with the bass/midrange driver that has a 1.5″ voice coil. Thus the A8X can play very low registers with a powerful punch, and the greatest possible precision. The 150 Watt PWM amplifier for the midrange speakers in conjunction with the 50 Watt A/B tweeter amp enable the A8X to generate impressive maximum sound pressure levels of 120dB per pair at one meter.
STATE OF THE ART TECHNOLOGY
ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.
In the Box:
Adam Professional Audio A8X 8.5" 200W Active 2-Way Studio Monitor (Single)
Power Cable
Not in the Box
Microphone and Signal Cables

Specifications

WOOFER
Number 1

Basket Ø 8.5" (220 mm)

Voice Coil Ø 1.5" (38 mm)

Cone Material Carbon / Rohacell / Glass Fiber

TWEETER
Number 1

Type X-ART

Diaphragm Area 4 inch² (2420 mm²)

Equiv. Diaphragm Ø 2" (56 mm)

Velocity Transform Ratio 4:1

Diaphragm Weight 0.17 g

BUILT-IN AMPLIFIERS
Woofer 1

Type PWM

Amp. Power RMS / Music 150 W / 225 W

Tweeter 1

Type A/B

Amp. Power RMS / Music 50 W / 75 W

CONTROL OPTIONS
Input Sensitivity -∞ to +14 dB

High Shelf EQ > 5 kHz ±6 dB

Low Shelf EQ 300 Hz ±6 dB

Tweeter Gain ±4 dB

INPUT CONNECTORS
Analog XLR / RCA

GENERAL DATA
Frequency Response 38 Hz - 50 kHz (-10 dB)

THD 90 dB / 1 m > 100 Hz ≤0.5 %

Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m ≥112 dB

Max. SPL per pair at 1 m ≥120 dB

Crossover Frequencies 2.3 kHz

Input Impedance 30 kOhm

Weight 28.7 lb (13 kg)

Magnetically Shielded No

Height x Width x Depth 15.5" (400 mm) x 10" (255 mm) x 12.5" (320 mm)

Panel Front

Delivery Contents Power cord, manual

ADAM Audio A8X 8.5" 200W Active 2-Way Studio Monitor (Single)
