The E110 is a compact, two-way loudspeaker with a 10-inch, die-cast frame woofer with a 2.5-inch voice-coil housed in a multi-purpose enclosure that’s at home in stage monitor or main PA deployment. It incorporates QSC’s Directivity Matched Transition® (DMT) design with a wide 85° coverage. When used as a stage monitor, the E110 is angled up at a 55° angle allowing it to be placed near the performer when used on a crowded stage.
E Series loudspeakers will perform very well with any quality, professional power amplifier – but by taking advantage of the complete E Series Entertainment System, more performance and options are available. Today’s powered loudspeakers rely on finely tuned digital signal processing (DSP) to achieve a higher level of performance. When used with QSC GXD or PLD amplifiers or with a QSC TouchMix digital mixer, E Series loudspeakers can also take advantage of advanced DSP. QSC has developed E Series DSP settings for all three platforms. These settings support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music, and karaoke.
In the Box
QSC E110 10" Two-Way Passive Loudspeaker (Black)
Limited 3-Year WarrantyNot in the Box
XLR & Signal CablesConfiguration: 1 x 10-inch, 2-way, non-powered
Frequency Range 1 (-10 dB): 50 Hz - 20 kHz
Power Capacity2 (Continuous/Peak): 300 W / 1200 W
Sensitivity: 95 dB, 1 W @ 1 m
Coverage Angle: 85° conical DMT
Output1 (Peak SPL @ 1m): 126 dB
Drivers: LF 254 mm (10-inch) driver with 64 mm 2.5-inch) voice coil, HF 25 mm (1-inch) exit, 45 mm (1.75-inch) voice coil, compression driver, Nominal Impedance 8 Ω
Cross-over: Full-range only, 1.8 kHz
Input Connectors: 2 x NL4 1 x barrier strip
Enclosure: Multi-angle, plywood, black texture paint finish, o ne top mounted handle, perforated, powder-coated steel grille with foam lining
Mounting and suspension: 6 x M8 suspension points, dual angle, 35 mm pole-socket
Net Weight: 20 kg / 44 lb
Shipping Weight: 23 kg / 50 lb
Dimensions (WxHxD): 13 x 22 x 13 in (330 x 560 x 330 mm)
