The E112 is a trapezoidal, two-way loudspeaker using a 12-inch die-cast aluminum woofer with a 3-inch voice coil. The 15mm, 11-ply enclosure provides enough volume to deliver solid low-frequency extension down to 65 Hz making it an excellent choice for applications in which space or budget preclude the use of a subwoofer. The DMT coverage angle of 85° is ideal for most medium and medium-long throw applications.
E Series loudspeakers will perform very well with any quality, professional power amplifier – but by taking advantage of the complete E Series Entertainment System, more performance and options are available. Today’s powered loudspeakers rely on finely tuned digital signal processing (DSP) to achieve a higher level of performance. When used with QSC GXD or PLD amplifiers or with a QSC TouchMix digital mixer, E Series loudspeakers can also take advantage of advanced DSP. QSC has developed E Series DSP settings for all three platforms. These settings support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music, and karaoke.
In the Box
QSC E112 12" Two-Way Passive Loudspeaker (Black)
Limited 3-Year WarrantyNot in the Box
XLR & Signal CablesConfiguration: 1 x 12-inch, 2-way, passive
Frequency Response (-6 dB): 64 Hz – 20 kHz
Frequency Range (-10 dB): 46 Hz – 20 kHz
Power Capacity1 (Continuous/Peak): 400 W / 1600 W
Sensitivity: 96 dB, 1 W @ 1 m
Coverage Angle: 85° conical DMT
Output2 (Peak SPL @ 1m): 128 dB
LF: 305 mm / 12-inch driver with 76 mm / 3-inch voice coil
HF: 25 mm / 1-inch exit, 45 mm / 1.75-inch voice coil, compression driver
Nominal Impedance: 8 Ω
Cross-over: Full-range only, 1.8 kHz
Input Connectors: 2 x NL4 1 x barrier strip
Enclosure: Trapezoidal, plywood, black texture paint finish. Two side-mounted handles. Perforated, powder-coated steel grille with foam lining.
Dimensions (WxHxD): 360 x 616 x 371 mm (14.2 x 24.2 x 14.6 in)
Net Weight: 23 kg / 51 lb
Shipping Weight: 26 kg / 57.5 lb
