TAO 1pro-S is a broadcasting streaming decoder with a 5.5 inch FHD preview display, but also a 4 channels seamless video switcher for 2 USB 3.0 and 1 HDMI 1.4 input, 1 SDI input and supports streaming directly by ethernet output which is ready to connect to external cloud based router and streaming from Anywhere to Everywhere.
TAO 1pro-S is compatible with standard USB 2.0 and USB 3.0 cameras by UVC protocol, and brings itself as a much affordable and user friendly streaming tools for anybody, the talents who is willing to be Anchor Online.
TAO 1pro-S is also with touch panel for finger configuration, and with optional 2 chargeable battery extending its capacity for outdoor application.In the Box:
RGBlink TAO 1pro-S Recorder-Switcher-Streamer
Connectors
Input HDMI 1.4 1×HDMI-A
SDI 1xBNC
USB 3.0 2×USB TypeA
Output HDMI 2.0 1×HDMI-A
Record USB 2.0 1×USB TypeA
Audio In 1×3.5mm Audio Jack
Out 1×3.5mm Audio Jack
Communication/Stream LAN 1×RJ45
Power 1×USB-C
Performance
Input Resolutions HDMI
SMPTE 720p@50/60 | 1080p@23/24/60
VESA 1024×768@60 | 1280×720@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 |
1600×1200@60 | 1680×1050@60 | 1920×1080@60
Output Resolutions HDMI
SMPTE 720p@50/60 | 1080p@24/25/50/60 | 2160p@60
VESA 1024×768@60 | 1280×720@50/60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 |
1920×1080@50/60 | 3840×2160@60
Supported Standard HDMI 1.4(Input) | 2.0(Output)
USB 3.0
Screen Feature
Screen Dimension 5.5 ’’TFT
Resolution 1080×1920 pixels
Dot Pitch 0.063(H)×0.021(W)(mm)
Aspect Ratio 16:9
Brightness 450cd/m²
Contrast 1000:1
Backlight LED
View Angle 80°/80°(L/R)80°/80°(U/D)
Power
Input Voltage 9V/2A
Max Power 18W
Environment
Temperature 0℃~55℃
Humidity 5%~85%
Physical
Weight Net 350g(without battery);882g(with battery)
Package 770g
Dimension Net 161mm×106mm×36mm
Package 255mm×145mm×85mm
