ADAM AUDIO SUB12
The Sub12 is a powerful subwoofer designed to extend the low frequency capabilities of any near or midfield monitoring system down to 22 Hz.A sturdy special woofer with extended cone travel and a heavy-duty coil have been optimized for accurate reproduction from a bass reflex enclosure. The down-firing bass reflex tube avoids intrusive ventilation noise because of its generous size and shape. The PWM amplifier produces over 90% efficiency and can handle critical passages without overheating for long periods of time. An additional output allows you to cascade as many subwoofers as needed.
The Sub12 subwoofer provides a precise combination of low cutoff frequency (-3dB at 22Hz) and an undistorted high sound pressure level (115dB SPL at 1m).
In the Box:
Adam Professional Audio Sub12 - 300W 12" Active Subwoofer
Not in the Box
Microphone and Signal CablesSUBWOOFER
Number 1
Basket Ø 12" (310 mm)
Voice Coil Ø 2" (50 mm)
Cone Material Paper
BUILT-IN AMPLIFIERS
Subwoofer 1
Type PWM
Amp. Power RMS / Music 200 W / 300 W
INPUT CONNECTORS
Analog XLR / RCA
GENERAL DATA
Frequency Response 22 Hz - 150 Hz
THD > 60 Hz ≤1 %
Max. peak SPL at 1 m ≥115 dB
Crossover Frequencies 50 - 150 Hz
Input Impedance 10 kOhm
Panel Rear
Weight 57.3 lb (26 kg)
Height x Width x Depth 23.5" (600 mm) x 14" (360 mm) x 17.5" (450 mm)
Delivery contents Power cord, manual
