Canare's thinnest profile audio hookup wire. Amazingly flexible, with 100% foil shield, drain wire, and PVC jacket that strips easily for rapid assembly. Suitable for large cable harness bundles, mixing consoles, tape machines, and inner-rack wiring.
- Microphones.
- Permanent Installations.
- Audio Patch Cords.PA Systems.
- Post Production Suites.
- Recording Studios.
- 100% Foil Shield Coverage w/Drain Wire.
- Built-in Dupont® Kevlar 29 and Drain Wire.
- Cross-Linked PE Insulation.
- Reduced Handling Noise.
- Rejects EMI and RFI.
In the Box
Canare L-2B2AT Twisted Pair Microphone Cable (200M, Black)If you would like to purchase 500m lengths, please specify in the notes and add the appropriate quantity to match the amount you are purchasing.
Std. Lng. ft. (m)
656 (200)Wt Std. Lng. lbs (kgs)
6 (3)Nom. O.D.in.(mm)
.126 (3.2)Jacket Nom. Thick. in. (mm)
.012 (0.3)Brittle Point F°(C°)
-13 (-25)No. of Cond.
2Insul. Type Thickmil
IPE 12.6Cond-AWG (Qty./mil) Cross Sec Area mil.
AC - #25 (16/4.73) 279Pitch Twist Quad in. (mm)
0.99 (25)Shield Coverage
100% Aluminum TapeCond. D.C.R. ohm/1000ft (ohm/100m)
31.9 (10.5)Shield D.C.R. ohm/1000ft (ohm/100m)
-Nom. Cap. pF/m
73Nom. Cap.† pF/m
120Nom. Imp. ohm
-Nom. Atten. V/1000ft (V/100m)
-Group Delay Time nS/ft (nS/m)
-
