New video converter that lets you receive a H.264 stream from any ATEM Mini Pro and convert it back to SDI and HDMI video so you can send it to remote locations around your local Ethernet network, or via the internet globally!
Stream to Yourself with ATEM Streaming Bridge!
The ATEM Streaming Bridge is a video converter that lets you receive a H.264 stream from any ATEM Mini Pro and convert it back to SDI and HDMI video. This means you can send video to remote locations around your local Ethernet network, or via the internet globally! That's possible because it uses advanced H.264 codecs for higher quality at very low data rates. Imagine broadcasters and bloggers collaborating on shows and creating global networks of ATEM Mini Pro remote broadcast studios. Setup is easy as the ATEM software utility can create setup files that you can email to remote ATEM Mini Pro studios. ATEM Streaming Bridge is the perfect way use ATEM Mini Pro as a remote broadcast studio!In the Box
Blackmagic Design ATEM Streaming Bridge for ATEM Mini Pro Streaming Switchers
Universal Power Supply with International AdaptersInput
Audio Input Connectors None
Output
Video Output Connectors 2 x BNC (3G-SDI / HD-SDI)
1 x HDMI (HDMI 1.4)
Output Video Format HDMI
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080i: 50/59.94/60 fps
SDI (10-Bit 4:2:2 YUV)
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080i: 50/59.94/60 fps
Audio Output Connectors None
Standards
Video Standard Compliance SMPTE 259M/292M/296M/424M-B/425M-A/425M-B
Connectivity
Other I/O 1 x RJ45
2 x BNC Reference
Expansion Slots None
IP Streaming
Video IP Decoding H.264: 1920 x 1080
Power
Power Connector 1 x Barrel (6 to 30 VDC) Input
Power Consumption Device: 6 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
Operating Humidity 0 to 90% (Recommended)
