Miniaturized broadcast quality SD and HD USB or AC powered converter that converts HDMI into SDI for use with professional broadcast monitors, decks, routers, switchers and more! Includes AC power supply with international socket adaptors.
In the Box
Blackmagic Design Micro Converter HDMI to SDI with Power Supply
Power Supply with International Socket AdaptersNot in the Box
HDMI/SDI Cables (Not Included)Connections
SDI Video Outputs
Automatically matches the SD, HD or 3G-SDI HDMI video input.HDMI Video Inputs
HDMI Type A in.Multi Rate Support
Auto detection of SD or HD.Updates, Configurations and Power
Micro USB.Reclocking
YesMicro Converter HDMI to SDI wPSU
Standards
SDI Video Standards
525i59.94 NTSC, 625i50 PALHD Video Standards
720p50, 720p59.94, 720p601080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425MSDI Video Rates
SDI video connections are switchable between standard definition and high definition, and user selectable level A and B via setup utility.SDI Color Precision
4:2:2SDI Color Space
YUVSDI Auto Switching
Automatically detects SD, HD and 3G-SDIHDMI Video Standards
525i29.97 NTSC, 625i25 PAL
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60HDMI Color Precision
4:2:2HDMI Color Space
YUVCopy Protection
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.Software
Software Control
Mac OSX™ and Windows™ software via micro USB.Internal Software Upgrade
Via micro USB.Operating Systems
Mac icon
Mac 10.14 Mojave,
Mac 10.15 Catalina or later.Windows Icon
Windows 8.1 and 10.Settings Control
Via software utility.Power Requirements
+5V universal power supply included with international socket adapters for all countries.Power Consumption
2.0 WattsOperational Voltage Range
4.4 to 5.25V DCPhysical Specifications
Micro Converter HDMI to SDI wPSU
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)Storage temperature
-20° to 60° C (-4° to 140° F)Relative Humidity
0% to 90% non-condensingWhat's Included
Micro Converter HDMI to SDI wPSU+5V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
