The Martin RUSH MH 11 Beam is a high-intensity beam moving head designed for high-end installations and rental applications. The RUSH MH 11 Beam utilizes the same 250W Platinum 11R lamp found in the Martin RUSH MH 7 Hybrid, but with refined beam optics that provide excellent intensity and sharp mid-air effects in a beam-only fixture. It also shares the same color temperature and palette with the RUSH MH 7 and MAC Axiom, for excellent color matching in a cost-effective beam-only fixture.
The high-intensity lamp combined with class-leading optics in the MH 11 allows the fixture to achieve sharp, high-output beam effects with a super-tight 2.6 degree beam angle. The fixture can produce a range of complex and precise mid-air looks utilizing 8 rotating and indexing gobos and an 8-facet prism. The fixture has 13 selectable colors and frost and motorized focus.
The fixture is a perfect fit for high-end live venue installations such as nightlife, houses of worship, and cruise ships. It also features a rugged industrial design for use in touring applications where Martin RUSH MH 7 and MAC Axiom fixtures are used.
Best-in-class optics for longer reach and greater impact
Feature-packed with a wealth of effects
Sturdy design built for the roadIn the Box
Martin Professional Lighting Rush MH 11 Beam - High-Intensity Moving Head
Power Cord
2 x Omega Bracket
Limited 1-Year WarrantyDYNAMIC EFFECTS
Electronic shutter effect: Strobe effect, pulse effects, instant open and blackout
Color wheel: 13 colors (incl. CTO and UV) + open, rotation with variable direction and speed
Rotating gobo wheel: 8 gobos + open, wheel rotation, gobo indexing, rotation and shake
Focus: Motorized, 16-bit coarse and fine control
Prism: 8-facet circular, indexing, rotation with variable direction and speed
Pan: 660°
Tilt: 250°
Pan and tilt speed: Adjustable via onboard control panel and DMX
Dimming: 0-100%, coarse and fine control
Frost
CONTROL AND PROGRAMMING
Control options: DMX, stand-alone, RDM
Setting and addressing: Control panel with backlit LCD display
DMX channels: 18
DMX compliance: USITT DMX512/1990
RDM compliance: ANSI E1.20
OPTICS
Cutoff beam angle: 2.6°
LAMP
Color temperature : 6800 K +/- 250 K
CRI (Color rendering index): 81
Average lifetime: 2000 hours*
Approved lamp: Philips MSD Platinum 11R 250 W
*Under manufacturer's test conditions.CONSTRUCTION
Housing: High-impact flame-retardant thermoplastic
Color: Black
Protection rating: IP20
GOBOS
Interchangeable rotating gobos:
Permitted material: Steel or aluminum
Diameter: 14 mm +/-0.2 mm (0.55 in. +/-0.008 in.)
Maximum image diameter: 13 mm (0.51 in.)
Gobo thickness: 0.8 mm (0.031–0.032 in.)INSTALLATION
Minimum clearance around fan and air vents: 200 mm (8 in.)
Mounting points: Two quarter-turn omega brackets for rigging clamps
Location: Indoor use only, must be fastened to surface or structure
Orientation: Any
Minimum distance to combustible materials: 200 mm (8 in.)
Minimum distance to illuminated surfaces: 10 m (33 ft.)CONNECTIONS
AC power in, thru: Neutrik TRUE1
DMX data in, thru: 3-pin and 5-pin locking XLRELECTRICAL
AC power: 100-120 / 200-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
TYPICAL POWER AND CURRENT
120 V, 60 Hz: 380 W, 3.5 A, PF 0.9
230 V, 50 Hz: 370 W, 1.7 A, PF 0.9
Measurements made at nominal voltage. Figures are typical, not maximum, allow for a deviation of +/- 10%.THERMAL
Cooling: Forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 0° C (32° F)
Total heat dissipation (calculated, +/- 10%): 1300 BTU/hr. (at full intensity, full white)APPROVALS
EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493
EU EMC: EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3
US safety: UL 1573
US EMC: CFR Title 47 Part 15 Class A
Canadian safety: CSA C22.2 No. 166
Canadian EMC: ICES-003 Class A
Australia/NZ: RCM (pending)INCLUDED ITEMS
Philips MSD Platinum 11R 250 W lamp (installed)
Power cable, 1.5 m (4.9 ft.), without mains plug
Two Omega clamp attachment brackets with 1/4-turn fastenersACCESSORIES (Optional item not included)
Philips MSD Platinum 11R 250 W lamp: P/N 50481205
Cables, 16 A, for connection to power in chains:
Power input cable, H07RN-F, 2.5 mm², 14 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91611797
Power input cable, H07RN-F, 2.5 mm², 14 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91611786
Power input cable, SJOOW, 12 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 1.5 m (4.9 ft.): P/N 91610173
Power input cable, SJOOW, 12 AWG, bare ends to Neutrik TRUE1 NAC3FX-W (female), 5 m (16.4 ft.): P/N 91610174Cables, 16 A, for relaying power in chains:
Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 0.45 m (1.5 ft.): P/N 91611784
Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 1.2 m (3.9 ft.): P/N 91611785
Power relay cable, H07RN-F, 2.5 mm², TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91611796
Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 0.45 m (1.5 ft.): P/N 91610170
Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 1.2 m (3.9 ft.): P/N 91610171
Power relay cable, SJOOW, 12 AWG, TRUE1 to TRUE1, 2.5 m (8.2 ft.): P/N 91610172Connectors:
Power connector, cable mount, Neutrik TRUE1 NAC3FX-W (female): P/N 91611789
Power connector, cable mount, Neutrik TRUE1 NAC3MX-W (male): P/N 91611788Installation hardware:
G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
Quick Trigger Clamp (suspension with fixture hanging vertically downwards only): P/N 9162007
Half-coupler clamp: P/N 91602005
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
