48-Channel, 28-Bus Full Stereo Digital Mixing Console, with 24-Midas PRO Preamps, 8 Midas PRO Outputs, 10" Touch Screen and 13-Fader Control Surface
Please note that only consoles originating from Loud Technologies Asia will be offered support and parts by the official Service Centre (LTAPL Service Centre). Consoles with no serial number or do not exist within the official LTAPL database will be refused support.
Features:- Dual-SD card live recorder/ player with up to 64 tracks and markers for identifying song positions
- Internal AoIP-module can upgrade the Ethernet ports with optional 64 channel audio in and out to Audinate Dante and Waves SoundGrid networks
- 16 True-stereo effects processing engines, with 80+ world-class algorithms
- 3 plug-in slots for Gate, Dynamics and EQ included in every channel. All without reducing any additional
- effect processing headroom
- 4 main, 8 matrix and 16 aux stereo buses, featuring dual inserts, 8-band parametric EQ’s, stereo imager and full dynamics processing, all in a single effect chain
- 40 Stereo Input Channels with 5 variable plug-in processing slots each
- 8 Stereo Aux Input Channels with single FX insert slot, expander/ limiter and 4-band parametric EQ
- 8 Mute Groups and 8 DCA’s for track grouping and consolidation
- 2 Ethernet ports with integrated switch for networked remote control and optional AoIP through Waves SoundGrid and Dante
- Rear panel expansion slot can host optional 64-channel audio interface and networking expansion cards, e.g. Dante, WSG, MADI
- StageConnect Host interface for sharing of up to 32 channels in either direction via single XLR connection
- 2 channel GPIO for controlling almost anything with WING
- 5-Pin MIDI in and out for control and synchronization with external devices
- DAW RemoteControl compatible with MackieControl Universal (MCU) and presetsfor Cubase, Ableton Live, Logic X,Nuendo, ProTools, Reaper,Studio One
- Offline editing and remote controlvia WING-CoPilot, WING-Q andWING-Edit Softwares for Desktopand Mobile
- 19" rack-mountable in 3 positions
Input/Output Characteristics
Frequency response @ 48 kHz sample rate, 0 to -1 dB (any gain setting)
10 Hz - 20 kHz
Dynamic range, analog in to analog out (typical), XLR / aux
111 dB / 108 dB
A/D dynamic range, preamplifier and converter (typical), XLR / aux
112 dB / 110 dB
D/A dynamic range, converter and output (typical), XLR / aux
118 dB / 112 dB
Crosstalk rejection @ 1 kHz, adjacent channels
100 dB
Output level, XLR connectors (nominal / maximum)
+4 dBu / +21 dBu
Output impedance, XLR connectors (unbalanced / balanced)
75 Ω / 75 Ω
Input impedance, TRS connectors (unbalanced / balanced)
20 kΩ / 40 kΩ
Non-clip maximum input level, TRS connectors
+16 dBu
Aux output level, TRS (nominal / maximum)
+4 dBu / +16 dBu
Aux output impedance, TRS (unbalanced / balanced)
150 Ω / 300 Ω
Phones output impedance / maximum output level
1W Max @ 30 Ohm
Residual noise level, XLR out 1-16 connectors, unity gain
-97 dBu
Residual noise level, aux and monitor TRS out connectors
-95 dBu
