Rolls RM85 Two-Zone Mic and Line Mixer

S$ 868.26
(S$ 868.26 excl GST)

Not shipping to UNITED STATES OF AMERICA Want this delivered today? Find out more

Add to cart Add to wishlist

What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!

Two-Zone Mic and Line Mixer

Key Features:

4 x XLR Balanced Inputs, +48V Phantom
4 x Stereo Source Inputs
Front Panel 1/8" Input
2 x Balanced Outputs
Low-Noise, Efficient Operation

Show more Show less

Introducing the RM85: Your Ultimate 8-Channel, Two-Zone Mixer
Experience unparalleled audio control with the RM85, an innovative 8-channel, two-zone mixer designed to meet all your professional audio needs. Whether you′re a seasoned audio engineer or a music enthusiast, this mixer is tailored to deliver top-notch performance.
The first four channels of the RM85 cater to both XLR microphones and XLR line level inputs, ensuring versatility in accommodating various audio sources. For added convenience, channels 5-8 offer 1/4" inputs, expanding your connectivity options.
Notably, all eight channels can be seamlessly routed to the two XLR outputs, granting you the freedom to choose from three configurations: A, B, or a combination of both A and B. This level of flexibility empowers you to craft the perfect audio output for any occasion.
Additionally, the RM85 boasts separate A and B outputs, both presented in XLR format. What′s more, you have the liberty to select either output as a Line or Microphone level output, tailoring the sound to your exact preferences.
As an added bonus, channel 8 is equipped with a convenient stereo 3.5mm (1/8") input located on the front of the mixer, further enhancing its versatility and usability.
Discover the true potential of your audio setup with the RM85 - a reliable, feature-rich mixer that raises the bar for professional-grade sound management. Elevate your audio experience today!
In The Box:
Rolls RM85 Two-Zone Mic and Line Mixer
Power Supply

Specifications

Input Impedance :
Mic: 600 Ohms XLR balanced
Line: 22 kOhms 1/4"

Maximum Input Level:
Mic: -14 dBV
Line: +24 dBV

Input Connectors:
4 x XLR
4 x 1/4" (6.3 mm) stereo pairs
1 x 1/8" (3.5 mm) stereo jack

Phantom Power:
+48 VDC

RCA Output Level and Impedance:
+17 dBV max (1 kOhm)

Maximum Gain:
Mic: 70 dB
Source: 30 dB

Noise Floor:
-80 dB

THD:
.025%

Signal to Noise Ratio:
96 dB

Voltage Gain:
32 dB

Supply Voltage:
Nominal: 15 VDC

Frequency Response:
20 Hz to 25 kHz

Power Supply:
Rolls PS27s, 15 VDC, 500 mA (tip negative)

Dimensions:
19 x 1.75 x 4" (48.3 x 4.5 x 10 cm)
Weight:
7 lb (2.3 kg)

Packaging Info
Package Weight:
4.9 lb
Box Dimensions (LxWxH):
21.5 x 8 x 3.8"
