    [product_name] => Neumann MA 1 Automatic Monitor Alignment Microphone
    [product_short] => Calibration Microphone
    [product_description] =>

RELIABLE MONITORING ANYWHERE

Neumann’s Automatic Alignment software MA 1 is a dedicated tool for aligning network-enabled KH Line monitors in stereo systems and stereo systems with Bass Management via an additional subwoofer. Non-network-enabled (analog) KH Line monitors can be aligned via MA 1 when connected to a KH 750 DSP/AES67 subwoofer.Unlike conventional correction software, MA 1 is an integrated solution with novel algorithms, specifically designed for Neumann studio monitors. No plug-in or special audio driver is required: Alignment data is stored and processed within the DSP-powered loudspeakers themselves. For analog Neumann studio monitors (i.e. without a network port) connected to a KH 750 DSP/AES67 subwoofer, MA 1 offers the added benefit of linearizing the phase response, too. This feature, which is already built into all network-enabled loudspeakers with digital electronics, is made possible for analog Neumann studio monitors by the KH 750’s DSP capabilities. The result is further increased accuracy in terms of tonality, impulse reproduction, and stereo localization.

HOW IT WORKS

As a first step, the performance of each monitor in the listening environment is gathered in a guided process. No special acoustics knowledge is required. Simply connect your KH line monitors to the outputs and the MA 1 microphone to the input of your audio interface. This Class I measurement microphone was specifically developed for this software and comes individually calibrated. For communication, the network-enabled KH-line monitors must also be connected to your computer via a network, a standard ethernet switch supporting IPv6 will do.From the measurement data, the software ascertains the room’s acoustic properties. The individual correction parameters are generated according to a room-specific target curve calculated by MA 1. Decades of experience in aligning reference monitoring systems in studio control rooms has been incorporated into this process. Of course, you can modify the target curve to your needs.When using Bass Management in stereo systems, the alignment algorithm ensures optimal summation between subwoofers and satellites. This achieves optimized time-of-arrival- andphase-correct combination of the monitors and the subwoofer, thus preventing the subwoofer from being perceived as a separate sound source. The result is a unified playback system.Multiple hardware systems and alignments can be conveniently saved, managed and recalled in MA 1.All alignment parameters are stored and processed in the network-enabled monitors. So, once aligned, there is nothing to worry about anymore, no plug-ins, no driver issues.After alignment, the ethernet connections can be removed from a technical perspective. However, keeping the network connections, the MA 1 software allows for advanced functions such as deactivating the subwoofer(s) or switching between different alignment presets (e.g. with a modified target curve).For more information, please refer to the MA 1 user manual: https://ma1.neumann.com/manual.

MULTICHANNEL EXTENSION

MA 1 Automatic Monitor Alignment delivers outstanding acoustic results for stereo setups. For aligning surround and immersive setups, Multichannel Extension for MA 1 is available as a paid extra license. For detailed information on Multichannel Extension for MA 1, go here.Using the KH 750 DSP subwoofer, stereo sets of analog KH-Line monitors, too, can be used with the Automatic Monitor Alignment Software. The KH 750 DSP has enough processing power to align the entire system including the two analog loudspeakers connected to its outputs. Additionally, KH 120, KH 310, and KH 420 loudspeakers profit from phase linearization of their built-in crossover filters! The result is increased clarity, a dry bass, and a time-correct, more accurate depiction of reverbs and acoustic spaces.



In the Box

Neumann MA 1 Monitor Alignment Microphone and Calibration System

Neumann SG105 Stand Clamp for KMS Vocalist Microphones

Calibration Software (Free Download)

[product_quantity] => -1 [product_code] => 508972 [product_published] => 1 [product_hit] => 20 [product_created] => 1720582279 [product_sale_start] => 0 [product_sale_end] => 0 [product_delay_id] => 0 [product_tax_id] => 11 [product_type] => main [product_vendor_id] => 0 [product_manufacturer_id] => 218 [product_url] => [product_weight] => 1.000 [product_keywords] => [product_weight_unit] => kg [product_modified] => 1720582936 [product_modified_by] => 11653 [product_meta_description] => RELIABLE MONITORING ANYWHERE Neumann’s Automatic Alignment software MA 1 is a dedicated tool for aligning network-enabled KH Line monitors in stereo systems and stereo systems with Bass Management via an additional subwoofer. Non-network-enabled (analog [product_dimension_unit] => cm [product_width] => 10.000 [product_length] => 20.000 [product_height] => 10.000 [product_max_per_order] => 0 [product_access] => all [product_group_after_purchase] => [product_min_per_order] => 0 [product_contact] => 0 [product_display_quantity_field] => 0 [product_last_seen_date] => 1721420355 [product_sales] => 0 [product_waitlist] => 0 [product_layout] => [product_average_score] => 0 [product_total_vote] => 0 [product_page_title] => [product_alias] => neumann-ma-1-automatic-monitor-alignment-microphone [product_price_percentage] => 0.0000000 [product_msrp] => 0.0000000 [product_canonical] => /category/product/7140-neumann-ma-1-automatic-monitor-alignment-microphone/category_pathway-69 [product_warehouse_id] => 1 [product_quantity_layout] => [product_sort_price] => 430.27523 [product_description_raw] => [product_description_type] => html [product_option_method] => [product_condition] => [product_key_feats] => Helps You Get Accurate, Consistent Mixes Allows Adjustments for Phase and Amplitude for Room Omnidirectional Calibration Microphone Fraunhofer IIS Calibration Algorithms Settings Stored in DSP Monitors Provides automatic monitor alignment for KH 80 DSP loudspeakers or non-DSP KH monitors via a KH 750 DSP subwoofer [product_lead_time] => [product_specs_all] =>

Acoustical operating principle: Pressure transducer

Directional Pattern Omnidirectional

Frequency Range 20 Hz - 20 kHz

Sensitivity at 1 kHz into 1 kohm 30 mV/Pa -30 dBV +/- 3 dB uncalibrated | 30 mV/Pa -30 dBV +/- 0,5 dB Calibrated (via software)

Rated Impedance 50 Ohms

Rated load impedance 1000 Ohms

Equivalent noise level, CCIR¹⁾39 dB

Equivalent noise level, A-weighted ¹⁾27 dB-A

Maximum SPL for THD 0.5% ²⁾132 dB

Signal-to-noise ratio, CCIR (re. 94 dB SPL) ¹⁾55 dB

Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾67 dB

Maximum output voltage 10 dBu

Supply voltage (P48, IEC 61938) 48 V ± 4 VCurrent consumption (P48, IEC 61938)3 mA

Matching connector XLR3F

Weight 37 g

Diameter 23 mm

Length 117 mm

Operating conditions 0 °C - +70 °C (32 °F - 158 °F); max. 90 % at +20 °C

Transport/storage conditions −20 °C - +70 °C (−4 °F - 158 °F); max. 90 % at +20 °C

[product_customs_cat] => audio_video [product_refund] => 0 [product_warranty] => [product_name_lta] => [product_short_lta] => [product_alt_search] => MA-1, MA1 [product_backinstock] => [product_specialorder] => 1 [product_soldout] => 0 [product_leadtime] => 5+ weeks [product_stock] => 0 [product_dl1_title] => [product_dl1_file] => [product_dl2_title] => [product_dl2_file] => [product_dl3_title] => [product_dl3_file] => [product_dl4_title] => [product_dl4_file] => [product_dl5_title] => [product_dl5_file] => [product_dl6_title] => [product_dl6_file] => [product_dl7_title] => [product_dl7_file] => [product_dl8_title] => [product_dl8_file] => [product_dl9_title] => [product_dl9_file] => [product_dl10_title] => [product_dl10_file] => [product_mpn] => 615104354548 [product_gtin] => 615104354548 [product_discontinued] => 0 [product_category_id] => 50187 [category_id] => 69 [ordering] => 313 [alias] => neumann-ma-1-automatic-monitor-alignment-microphone [options] => Array ( ) [bundles] => Array ( ) [images] => Array ( [0] => stdClass Object ( [file_id] => 21305 [file_name] => ma1-2 [file_description] => [file_path] => ma1-2.jpg [file_type] => product [file_ref_id] => 7140 [file_free_download] => 0 [file_ordering] => 0 [file_limit] => 0 ) [1] => stdClass Object ( [file_id] => 21304 [file_name] => ma1-1 [file_description] => [file_path] => ma1-1.jpg [file_type] => product [file_ref_id] => 7140 [file_free_download] => 0 [file_ordering] => 1 [file_limit] => 0 ) ) [prices] => Array ( [0] => stdClass Object ( [price_id] => 6420 [price_currency_id] => 140 [price_product_id] => 7140 [price_value] => 430.27523 [price_min_quantity] => 0 [price_access] => all [price_users] => [price_site_id] => [price_start_date] => 0 [price_end_date] => 0 [price_value_with_tax] => 430.27523 [taxes_added] => 1 [taxes] => Array ( ) ) ) [badges] => [userID] => 0 [userZone] => 223 [userCountry] => United States of America [brandObj] => stdClass Object ( [category_id] => 218 [category_parent_id] => 10 [category_type] => manufacturer [category_name] => Neumann [category_description] =>
Neumann

Many products introduced in Neumann's history have become milestones of professional audio technology. It is no accident that when listing their equipment, audio studios almost always put Neumann at the top of the list.
Based on Neumann's decades of success and its uncompromising, quality-oriented approach in both development and manufacture, you can be certain to acquire products with unsurpassed sound quality, reliability and lasting value.

AVLFX / Loud Technologies Asia is an official reseller for Neumann.

[category_published] => 1 [category_ordering] => 60 [category_left] => 437 [category_right] => 438 [category_depth] => 2 [category_namekey] => manufacturer_1593402589_1226355426 [category_created] => 1593402589 [category_modified] => 1593419255 [category_access] => all [category_menu] => 0 [category_keywords] => [category_meta_description] => Choose from a wide range of Neumann microphones, headphones, studio monitors and other accessories for purchase and shipping from Singapore. Fast shipping! [category_layout] => [category_page_title] => Buy Neumann Microphones and other products online from Singapore's Premier AVL Superstore [category_alias] => neumann [category_site_id] => [category_canonical] => /brand/218-neumann [category_quantity_layout] => [brand_ships_to] => ship_Sennheiser_1193671771 [category_refund] => 1 [category_banner] => banner-neumann.jpg [category_alt_search] => ) [can_sell] => 1 )

Neumann MA 1 Automatic Monitor Alignment Microphone

S$ 430.28
(S$ 430.28 excl GST)
Special order! Expected availability: 5+ weeks Not refundable/exchangeable
What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!

Calibration Microphone

Key Features:
  • Helps You Get Accurate, Consistent Mixes
  • Allows Adjustments for Phase and Amplitude for Room
  • Omnidirectional Calibration Microphone
  • Fraunhofer IIS Calibration Algorithms
  • Settings Stored in DSP Monitors
  • Provides automatic monitor alignment for KH 80 DSP loudspeakers or non-DSP KH monitors via a KH 750 DSP subwoofer
Show moreShow less
  • RELIABLE MONITORING ANYWHERE

    Neumann’s Automatic Alignment software MA 1 is a dedicated tool for aligning network-enabled KH Line monitors in stereo systems and stereo systems with Bass Management via an additional subwoofer. Non-network-enabled (analog) KH Line monitors can be aligned via MA 1 when connected to a KH 750 DSP/AES67 subwoofer.Unlike conventional correction software, MA 1 is an integrated solution with novel algorithms, specifically designed for Neumann studio monitors. No plug-in or special audio driver is required: Alignment data is stored and processed within the DSP-powered loudspeakers themselves. For analog Neumann studio monitors (i.e. without a network port) connected to a KH 750 DSP/AES67 subwoofer, MA 1 offers the added benefit of linearizing the phase response, too. This feature, which is already built into all network-enabled loudspeakers with digital electronics, is made possible for analog Neumann studio monitors by the KH 750’s DSP capabilities. The result is further increased accuracy in terms of tonality, impulse reproduction, and stereo localization.

    HOW IT WORKS

    As a first step, the performance of each monitor in the listening environment is gathered in a guided process. No special acoustics knowledge is required. Simply connect your KH line monitors to the outputs and the MA 1 microphone to the input of your audio interface. This Class I measurement microphone was specifically developed for this software and comes individually calibrated. For communication, the network-enabled KH-line monitors must also be connected to your computer via a network, a standard ethernet switch supporting IPv6 will do.From the measurement data, the software ascertains the room’s acoustic properties. The individual correction parameters are generated according to a room-specific target curve calculated by MA 1. Decades of experience in aligning reference monitoring systems in studio control rooms has been incorporated into this process. Of course, you can modify the target curve to your needs.When using Bass Management in stereo systems, the alignment algorithm ensures optimal summation between subwoofers and satellites. This achieves optimized time-of-arrival- andphase-correct combination of the monitors and the subwoofer, thus preventing the subwoofer from being perceived as a separate sound source. The result is a unified playback system.Multiple hardware systems and alignments can be conveniently saved, managed and recalled in MA 1.All alignment parameters are stored and processed in the network-enabled monitors. So, once aligned, there is nothing to worry about anymore, no plug-ins, no driver issues.After alignment, the ethernet connections can be removed from a technical perspective. However, keeping the network connections, the MA 1 software allows for advanced functions such as deactivating the subwoofer(s) or switching between different alignment presets (e.g. with a modified target curve).For more information, please refer to the MA 1 user manual: https://ma1.neumann.com/manual.

    MULTICHANNEL EXTENSION

    MA 1 Automatic Monitor Alignment delivers outstanding acoustic results for stereo setups. For aligning surround and immersive setups, Multichannel Extension for MA 1 is available as a paid extra license. For detailed information on Multichannel Extension for MA 1, go here.Using the KH 750 DSP subwoofer, stereo sets of analog KH-Line monitors, too, can be used with the Automatic Monitor Alignment Software. The KH 750 DSP has enough processing power to align the entire system including the two analog loudspeakers connected to its outputs. Additionally, KH 120, KH 310, and KH 420 loudspeakers profit from phase linearization of their built-in crossover filters! The result is increased clarity, a dry bass, and a time-correct, more accurate depiction of reverbs and acoustic spaces.



    In the Box

    Neumann MA 1 Monitor Alignment Microphone and Calibration System

    Neumann SG105 Stand Clamp for KMS Vocalist Microphones

    Calibration Software (Free Download)

  • Acoustical operating principle: Pressure transducer

    Directional Pattern Omnidirectional

    Frequency Range 20 Hz - 20 kHz

    Sensitivity at 1 kHz into 1 kohm 30 mV/Pa -30 dBV +/- 3 dB uncalibrated | 30 mV/Pa -30 dBV +/- 0,5 dB Calibrated (via software)

    Rated Impedance 50 Ohms

    Rated load impedance 1000 Ohms

    Equivalent noise level, CCIR¹⁾39 dB

    Equivalent noise level, A-weighted ¹⁾27 dB-A

    Maximum SPL for THD 0.5% ²⁾132 dB

    Signal-to-noise ratio, CCIR (re. 94 dB SPL) ¹⁾55 dB

    Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾67 dB

    Maximum output voltage 10 dBu

    Supply voltage (P48, IEC 61938) 48 V ± 4 VCurrent consumption (P48, IEC 61938)3 mA

    Matching connector XLR3F

    Weight 37 g

    Diameter 23 mm

    Length 117 mm

    Operating conditions 0 °C - +70 °C (32 °F - 158 °F); max. 90 % at +20 °C

    Transport/storage conditions −20 °C - +70 °C (−4 °F - 158 °F); max. 90 % at +20 °C
