DANTE 2CH PRO INPUT ADAPTER INCL. OUTPUT GAIN
The AU-X2IPRO-DA from TiGHT AV effortlessly integrates two channels of analog audio into your Dante network. Utilizing Audinate’s original Dante Ultimo chip, the unit supports sample rates up to 96kHz.Featuring an installer-friendly interface equipped with phoenix analog connectors, input sensitivity settings via dip switch, a reset button, and a rugged metal housing, the AU-X2IPRO-DA offers simplicity and cost-efficiency. It provides a straightforward solution for seamlessly connecting analog equipment to a Dante network in professional installations.
For simplified setup, PoE support enables easy installation using a PoE-capable network switch or a separate power supply. Additionally, optional Phoenix to XLR cables are available, offering increased connectivity options.
KEY FEATURES
• Plug and Play
• 2 audio inputs with selectable sensitivity per input
• Dante and AES67 support
• 24-bit audio support
• Supports 802.3af PoE
• Dante Controller and Dante Domain Manager compatible
• Install friendly
• Optional local power
• Rugged metal housing
• Mounting ears
• Reset buttonAUDIO
Max output level (balanced): +18 dBu / +4 dBu / 0 dBu/ 0 dBV /-10 dBV
Frequency Response: 20Hz to 20kHz (-/+0.5dB)
Impedance: 150 Ohm (balanced) or 75 Ohm (unbalanced)
Dynamic Range: >100 dB
Signal to Noise Ratio: >100 dB
THD: 0.01% @+4 dBu
DANTE
Sample Rate: 44.1kHz, 48kHz, 96kHz
Bit Depth: 24
Dante Device Latency: 1, 2 or 5ms (configurable using Dante Controller)
Network Transport: Dante Audio over IP
AES67 RTP
GENERAL
Operation Temperature: -5°C to +55°C (+23°F to +131°F)
Storage Temperature: -25°C to +70°C℃(-13°F to +158°F)
Power: 802.3af PoE or 12V DC
Power Consumption: 2.6W (Max)
Dimension (W x H x D): 128 x 26 x 48 mm
Net Weight: 195g
Compliance: FCC, CE
Environmental: RoHS, REACH, WEEE
