The RA63b is an eight channel mono, or four channel stereo distribution amplifier designed for the contractor / install market. The outputs are designed to drive high-level balanced lines in a sound distribution system. The screw terminals on the rear panel are for input and output, and each output may power more than one line.
The RA63b replaces the old RA63s. The new ra63b has all the same features, but has an easy access stereo mono switch.
• Stereo 4 channel, Mono 8 channel audio distribution
• Screw driver adjustable front panel volume controls
• Balanced inputs and outputsInput Impedance: 100 KΩ balanced
Max Input Level: +22 dBV
I/O Connectors: 5 pin Pluggable Phoenix screw terminals; + -, and ground
Output Impedance: 50 Ω balanced
Max Output Level: +24 dB
Max Gain: 20 dB
S/N Ratio: >90 dB
Frequency Response: 10 Hz - 40 kHz, +/- 1 dB
THD: .008%
Power: 120 VAC 50-60 Hz, 15VA
Size: 19” x 1.75” x 6.5” (48 x 4.5 x 17 cm)
Weight: 7 lbs. (3 kg)
