Datavideo HDR-1 Standalone H.264 Recorder and Player

S$ 770.00
(S$ 770.00 excl GST)
Out of stock
What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!

Replaced by NVS-35

Key Features:
  • Records HD and SD Video to H.264 Files
  • USB Flash Drive Recording Media
  • HDMI I/O
  • Play Back and Edit Recorded H.264 Video
  • DISCONTINUED, now replaced by:

    https://www.avlfx.com/category/product/5976-datavideo-nvs-35/category_pathway-199



    Record and playback HD videos in the ubiquitous H.264 format without a PC using the Datavideo HDR-1 Standalone H.264 Recorder and Player. To get started, plug in an NTFS-formatted USB flash drive, and the HDR-1 will automatically set itself up to record or playback video to/from the drive. Whether your productions have HD or SD equipment, the HDR-1 can handle it. Resolutions of up to 1080p at 30fps are supported for recording, and bit-rates of up to 20 Mbps ensure that the recordings retain detail.

    Once your video is recorded, you can remove the flash drive and distribute the video, or move it to a hard drive for archiving, sharing directly to the web (no transcoding required for most hosting services), or editing later. Basic editing maneuvers, such as cutting unwanted segments can be made inside the HDR-1. If someone is actively operating the HDR-1, the pause button can temporarily stop the recording during a break in the event while keeping the recording in a single file, removing extra post-event editing steps.

    Existing H.264 videos can be loaded onto a flash drive for playback on the HDR-1. Connect an HDMI display and use the front-panel controls or software control via RS-232 to navigate files and control playback. RS-232 and GPI can also control recording start/stop with separately available hardware as part of a larger A/V setup.



    Features:

    Capture HD video up to 1080p30
    Video pass-through
    Records and plays back standard MP4 files (H.264+AAC)
    Standard USB flash drives for recording media
    Does not require a PC for operation
    3-20 Mbps bit-rate options (resolution dependent)
    Basic integrated editing functionality
    Supports 3D video formats



    In the Box:
    1 x HDR-1 product
    1 x AD Switch DC 12V
    1 x USB Thumb Drive

  • Video Standard
    HD & SD

    Video Format
    1080p 50/60
    1080i 50/60
    720p 50/60
    480i/480p/576i/576p

    Supported Video Input Signal
    1x HDMI

    Monitoring / Playback Output
    1x HDMI

    Embedded Audio
    2ch pcm

    Storage Medium
    USB Flash Drive

    Estimated Record Time (min per 10GB)
    SD 16GB: 4.2Hr (7.5Mbps)~ 10Hr (3Mbps)
    HD 16GB: 1.5Hr (20Mbps)~ 2Hr (15Mbps)

    Recording Media
    USB Flash Drive,
    SD Card (USB adapter required)
    HDD/ SSD (via USB2.0)
    Storage File System
    NTFS

    Recorded File Format
    MP4 (H.264+ AAC)

    Video Recording Bit Rate / Color Sampling
    YUV 4:2:0 / 12bit

    Audio Recording Format
    AAC 2CH,
    16bit 48KHz 128Kbps

    External Control
    RS-232 (Dsub 9pin), GPI (3.5Ø phone jack)

    Power Failure Protection
    Redundant USB power supply (not included)

    Chassis
    1RU, Half-rack Width

    Dimension (LxWxH)
    220 x 211 x 42 mm

    Weight
    1.3 kg

    Operating Temp. Range
    0~40 °C

    Power
    DC 12V, 0.5A

For export (= shipments outside of Singapore) we do not charge GST. In this case, please refer to the prices excl GST.
