PreSonus EarMix 16M - 16x2 AVB-Networked Personal Monitor Mixer | Buy PreSonus direct from Singapore's Authorized Dealer for warranty assurance.
The Presonus EarMix 16M is a 16-channel personal monitor mixer that is compatible with all StudioLive Series III mixers, as well as with other AVB-enabled systems. The EarMix 16M mixes 16 mono channels via AVB networking and provides stereo channel linking and channel grouping along with three-band EQ and limiting for each channel as well as the main mix. For outputs, the unit offers a pair of balanced 1/4" TRS connectors as well as a 1/4" headphone output with a loud, clear headphone amplifier capable of driving low impedance devices such as high-quality in-ear monitors. The two AVB jacks enable daisy-chaining up to 24 EarMix units with a StudioLive Series III mixer. The EarMix 16M can be powered by the included external power supply or over Ethernet (PoE) from a compatible switch.
Analog Input/Output
1/8" stereo aux input
2 x balanced 1/4" TRS line outputs
1/4" TRS stereo headphone output with loud, clear headphone amp that can drive low-impedance in-ear monitors
Meters, Controls, and Processing
3-band EQ with sweepable mid frequency on all channels and main mix
Limiter on all channels and main mix
Stereo channel linking
Channel grouping
Solo and mute
Mix scene Store and Recall; store up to 16 mix scenes locally
16 x signal present and clip LEDs (one for each input)
8-segment stereo output meter
Channel Level rotary control with 8-segment level indicator
Aux input level control
Independent monitor (line out) and phones level controls
Routing setup from StudioLive Series III consoles and UC Surface
Digital
16 x mono channels of input via AVB networking
2 x AVB Ethernet ports
24-bit, up to 48 kHz operation
Power
External 24 VDC power supply (included)
Support for PoE power
Physical
Optional mic stand mount (sold separately)In the Box
PreSonus EarMix 16M - 16x2 AVB-Networked Personal Monitor Mixer
Power Supply
Limited 1-Year WarrantySales within Singapore: "Products are supplied with a standard 1-year warranty supported through the Singapore Authorised Distributor for Presonus"
Sales to customers outside of Singapore: Products are supplied with a standard 1-year warranty. RMA requests will be coordinated through Singapore.
PreSonus EARMIX 16M Specifications:
Analog Inputs and Outputs Aux Input: 1 x 1/8" / 3.5 mm TRS
Line Output: 2 x 1/4" / 6.35 mm TRS
Headphone: 1 x 1/4" / 6.35 mm TRS
Digital 16 x mono channels of input via AVB networking
2 x AVB Ethernet ports
24-bit, up to 48 kHz operation
EQ Section 3-band EQ with sweepable mids on all channels and main mix
Limiter Yes, all channels and main mix
Stereo Linking Stereo channel link
Groups Channel grouping
Indicators and Controls 16 x track select
1 x solo
1 x mute
16 x signal present and clip LEDs (one for each input)
8-segment stereo output meter
1 x channel level rotary control with 8-segment level indicator
1 x aux input level control
1 x independent monitor (line out)
1 x phones level control
Presets Mix scene store and recall
Store up to 16 mix scenes locally
Power External 24 VDC power supply
Supports PoE power
Dimensions Not specified by manufacturer
Weight Not specified by manufacturer
