Blaze PowerZone Connect 1008D Power Amplifier

S$ 3,840.00
(S$ 3,840.00 excl GST)
Not shipping to UNITED STATES OF AMERICA Not refundable/exchangeable
Add to cart Add to wishlist
What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!

1000 W DSP-enabled Dante Class-D amplifier with 8 channels

Key Features:
  • Full rack form factor
  • Flexible power sharing across output channels
  • Hybrid power distribution in both Lo-Z and Hi-Z
  • Full-matrix DSP configuration via PowerZone™ Control web app ( built-in )
  • Dante Enabled
Show moreShow less

  • The PowerZone Connect 1008D is a solid, reliable, full rack, DSP amplifier with network connection for easy configuration and control.


    Features
    • Full rack form factor
    • Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
    • Hybrid power distribution in both Lo-Z and Hi-Z
    • Powered by Pascal UMAC™ Class-D technology
    • Flexible power sharing across output channels
    • UREC™ universal power supply with PFC
    • S/PDIF input/output
    • Configurable GPIO
    • ErP and Energy Star compliant
    • UL listed audio equipment
    • Dante enabled


    PowerZone™ Connect 2U series

    The PowerZone™ Connect 2U series is a line of ultra-reliable, full-matrix DSP-enabled Class-D amplifiers that delivers exceptional system configuration and flexible output, with a total system power ranging from 1000W to 3000W. The PowerZone™ Connect 2U series powers both conventional low-impedance (2Ω to 16Ω) loudspeakers and constant voltage (70V/100V) transformer-coupled loudspeakers, and features automatic power-sharing technology for proportional distribution in both Lo-Z and Hi-Z modes. Our intuitive PowerZone™ Control web app is built into all our PowerZone™ Connect amplifiers for easy system setup. PowerZone™ Control facilitates effortless customization of even the most challenging audio/voice systems by delivering many DSP configuration options and tuning features, including multi-zone setup, input mixing, priority and ducking, restriction, input and output EQ, S/PDIF output routing, high-pass filter, speaker presets, delay, Wall-S1 controller configuration, Sine generator, and much more. The amplifiers have built in WirelessAccess-Point (WAP) for the simple connection and easy system setup via Wi-Fi.

    Our web app, PowerZone™ Control, is the most versatile DSP controller available for configuring audio/voice systems in locations requiring multi-zone audio set up with multiple mic talk overs. PowerZone™ Control facilitates effortless customization of even the most detailed audio/voice systems and adept management of multiple DSP configurations and tuning features, such as multi-zone setup, input mixing, priority and ducking, restriction, input and output EQ, S/PDIF output routing, high-pass filter, speaker management and presets, delay, Wall-S1 controller configuration, Sine generator, and much more. PowerZone™ Control caters to the demanding requirements of advanced system installs in locations such as retail stores, restaurants, hotels, educational facilities, theatres, bars, cafes, fitness locations, vast hospitality spaces, and spaces with multiple meeting/conference rooms. PowerZone™ Control is embedded in our PowerZone™ Connect full Matrix DSP amplifiers, and can be accessed from any device and browser via the PowerZone™ Connect built-in Wi-Fi or RJ45 network port.

    Application
    - Shopping Malls
    - Large scale paging & Distribution
    - Auditoriums
    - Hotels & Conferences
    - Entertainment
    - Casinos

  • Total System Power
    1000 W

    Output Power @ 4/8Ω
    8 x 125 W

    Output Power @ 70/100V*
    4 x 250 W

    Powershare (up to) Across all channels**
    4 x 250 W

    Power Consumption
    300 W

    Dimensions
    44 x 440 x 319 mm
    1.7 x 17.3 x 12.6 in

    Weight
    3.8 kg, 8.4 lbs

    Output Circuitry
    UMAC™ Class D – full bandwidth PWM modulator with ultra-low distortion

    Output Voltage
    45Vrms (S.E) – 70/100V (Hi-Z)

    Signal To Noise-Ratio
    > 100 dB (A-weighted, 20 Hz – 20 kHz, 8 Ω load)

    THD+N (typical)
    0.05 % (20 Hz – 20 kHz, 8 Ω load, 3 dB below rated power)

    Frequency Response
    20 Hz – 20 kHz (+0/-0.25 dB (8 Ω load, 3 dB below rated power)

    Protection Circuits
    Short circuit protection, DC protection, under voltage protection, temperature protection, overload protection

    Power Supply
    UREC™ universal mains switch mode power supply with Power Factor Correction (PFC)
    and integral standby converter

    Operating Voltage/Frequency.
    Universal Mains, 100-240V, 50-60Hz

    Operating temperature
    0-40°C

    Standby Consumption
    0.5 W (Energy Star & ErP 1275/2008/EC compliant)

    Power Ratings
    1% THD @ 120VAC and 230VAC
