The MX401 mixes 4 microphones or line level XLR′s into two balanced Stereo outputs. The four XLR inputs, each have individually switchable phantom power, MIC or LINE level switch, Level control, and a Pan control. Two independant balanced, XLR outputs both with selectable MIC or LINE level. 1/8" inch Stereo Aux/Headphone output has been provided along with a Clip indicator, Power indicator, and Power switch. The unit is also powered by two 9-Volt alkaline batteries or the included 15VDC power supply. The MX401 replaces the previous MX124.
Features
- Four balanced XLR Inputs
- Two balanced XLR Outputs
- Switchable Output Level ( Line level, or mic)
- Switchable Phantom Power for each input
- Level controls for each channel
- 3.5mm Stereo Output
- Rolls PS27s 15 VDC external power supply included
- Powered by two 9 volt batteries or the included power supply
In the Box
1 - Made in USA MX401
1 - 15V power supply PN PS27s
1 - Owners manualInput Impedance: 600 Ohms MIC - 10k Ohms LINE
Output Impedance: 600 Ohms MIC - 10k Ohms LINE
THD Noise:.02%
S/N Ratio: 96 dB
THD Noise: .02%
Self Noise: -65 dB maximum, -90 dB typical
Frequency Response: 20 Hz - 20kHz ( 0 / -3 dB )
Max Output Level: 14 dB
Max Gain: 55 dB
Current Draw: 30 mA with no Phantom Power or Signal
Phantom Power: 15 VDC
Power: 12-15VDC / 300-500 mA
Size: 8.5”w x 5.75”d x 1.5” h
Weight: 2.05 lbs.
