ultra-portable pro-mixer and audio interface
TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine.
mix 6 stereo input channels, use tempo sync, discover the internal synthesizer and sequencer or use the built-in tuner. MFi compatibility even lets you connect to your iOS devices.smallest of its kind.
TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose to have the three-band eq at your fingertips, or customize each
knob to control whichever setting you prefer. with more than meets the eye, TX–6 is packed full of features and connectivity options.battery powered
the rechargeable battery holds for about 8 hours. for energy efficiency, the display automatically goes to sleep when not in use, and led strength is completely adjustable.
synthesizer & sequencer
TX–6 also functions as a portable synthesizer and sequencer with 4 oscillator waveforms and 4 synthesized drum sounds. use tempo sync to stay on the beat.
8 built-in effectsexplore send effects like reverb, chorus and delay, and creative effects freeze, tape, filter, and distortion. each channel has a three-band eq and adjustable compressor.
quality and engineeringTX–6 is a sturdy little machine. encased in cnc aluminum with 2k molding, custom-made encoders and faders, and custom pcb - engineered for portability.
wireless connectivitywith ble, you can use TX–6 as a wireless controller for other ble midi devices or trigger and sync the internal synth and sequencer from other sources.
super slimline cableshigh quality, slimline cables custom-made for TX–6. the narrow profile allows you to use all 6 channels at once and makes for an easy pack down.
customizable interface
when you're ready for the studio, use TX–6 as a 12 channel audio interface and connect to any daw over usb-c. MFi also allows you to connect to iOS devices.
dj mode
turn TX–6 on its side and use it as a dj mixer. turn channel 1 into a fader to crossfade between the channel 5 and 6 so you can fade or cut between the two.
6.35 + 3.5 mm output
connect your audio output through 3.5 mm mini jack or use the included and removable 6.35 mm jack to 3.5 mm mini jack adapter.
field bags
designed to fit TX–6 field mixer and constructed in heavy duty fabric and hardware, field bags are designed for durability, ready to be used out in the field.
In the Box:
teenage engineering TX-6 Ultraportable Pro-Mixer, Audio Interface, and Recorder
USB-C CableTX-6 highlights
6 stereo input connectors
2 stereo output connectors
1 stereo headphones connector with headset microphone support
usb audio / midi interface
bluetooth low energy radio interface
rechargeable battery
8h battery life
48x64 pixel monochrome displayinputs and outputs
24-bit/48kHz usb interface
3.5 mm mini jack to 6.3 mm jack
headset mic input
aux output
connect to iPhone®, lightning cable
stereo or mono for each inputdimensions and weight
90 mm (102 mm with adapter) x 62 mm x 23 mm
160 g / 5.6 ozelectrical characteristics
audio inputs:
impedance 10 kOhm
analog gain 0 - 42 dB
max level 8 dBu, 2 Vrms
TLV320ADC3140 burr-brown™
SNR ~ 102 dBAaudio output (main and aux):
max level 8 dBu, 2 Vrms
cirrus logic masterhifi CS43131
SNR > 120 dBAaudio output (cue):
max level 2 dBu, 1 Vrms
cirrus logic CS47L35
SNR > 110 dBA
handlingambient working temperature:
0-50°C (32-122°F)ambient storage temperature:
0-30°C (32-86°F)clean the shell of the unit with a microfibre cloth. use pressurized air to remove dust from the faders.
to keep the battery healthy, the unit should be charged at least every 6 months. if not used for a long time, it may not charge again.
