Yamaha CHR10 2-Way 10

Performance. Optimized.
The CHR Series offers an ideal solution for anyone ready to step up their sound reinforcement game to a new level of professional quality, accuracy, and performance. Premium plywood cabinets finished in a tough polyurea coating provide durability not found on other loudspeakers in this class.
Each model in the series has been optimized to meet the demands of a variety of sound reinforcement applications, with a 10” model for fixed installation and utilities, a 12” model designed for use as a floor monitor, and a 15” version for FOH applications —all featuring carefully selected custom transducers. Combined with practical features adapted for their specific applications, the series gives you the flexibility to choose the ideal speaker for a wide variety of sonic environments. Isn’t it time you audition CHR quality and performance to improve your sound?
The CHR10 is a 2-way loudspeaker, equipped with a 10-inch woofer and a 1.4-inch HF driver, and perfect for use in fixed installations. Combining carefully selected and customized transducers with the same high-grade plywood construction found on Yamaha’s high-end CZR Series, the CHR10 offers best-in-class sound quality and durability.
- Featuring a plywood cabinet that delivers a clear sound with minimal vibration
- Plywood enclosure with a polyurea coating for a robust, scratch resistant surface
- Compact appearance thanks to the 10-inch LF driver that provides excellent low frequency response
- Can be installed in a horizontal or vertical configuration with a rotatable HF horn offering the flexibility needed for installation in a wide range of environments
- Optional UB-DXRDHR10 U-bracket allows both for vertical or horizontal use
- A pole socket for use on a stand
- Rigging points for use with eye bolts
- Yamaha DSP equipped amplifiers or other compatible signal processors have dedicated speaker processor tuning settings to maximize system performance
In the Box:
Yamaha CHR10 2-Way 10" Passive Loudspeaker

Specifications

Configuration Passive 2-Way

Enclosure Type Bass-Reflex Loudspeaker

Total Power Capacity
175 W RMS
350 W Program
700 W Peak

Constant Voltage / Transformer Taps None

System Impedance 8 Ohms

Drivers
HF Driver 1 x 1.4" / 35.6 mm Rotatable Horn Compression Driver with 1" / 25 mm Throat

MF Driver None

LF Driver 1 x 10" / 254 mm Woofer

LF Voice Coil 2" / 50.8 mm

Magnet Ferrite

Performance
Frequency Range 55 Hz to 20 kHz -10 dB

Maximum SPL 122 dB

Coverage Angle 90° H x 60° V (Rotatable Horn)

Speaker Sensitivity 93 dB SPL

Connectivity
Audio I/O 2 x speakON NL4 Speaker Input/Thru (Lockable)

Signal Processing
Crossover 2.5 kHz

Phase Adjustment None

Physical
Mounting
2 x M10 Fly Point (Top)
1 x M10 Fly Point (Rear)
1 x 1.4" / 35 mm Pole Socket (Bottom)

Handles 1 x Top

Construction Material Perforated Metal Grille, Plywood, Polyurethane

Dimensions 19.5 x 12 x 11.8" / 495.3 x 304.8 x 299.7 mm

Weight 30.2 lb / 13.7 kg

Yamaha CHR10 2-Way 10" Passive Loudspeaker
