Yamaha CZR10 700W 2-Way 10" Passive Loudspeaker (Black)

S$ 1,058.00
(S$ 1,058.00 excl GST)
Not shipping to UNITED STATES OF AMERICA Not refundable/exchangeable

 Please select your add-on:

Adam Hall Stands - SPS 023 SET Speaker stand (pair) with carry bag
What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!
Key Features:
  • For Live Stage, Theatre, DJ Setups
  • Designed for FOH/Main or Floor Monitor
  • LF: 10" and HF: 2"
  • Max SPL: 127 dB (Bi-Amp: 131 dB)
  • Frequency Range: 43 Hz to 20 kHz (-10 dB)
  • Power Rating: 700W (Program)
  • 2 x speakON NL4MP (Parallel)
  • Passive or Bi-Amp Configurable
  • Rotatable Horn
  • 2 x Pole Sockets (0 or -7°)
Show moreShow less
  • Superior Power-Handling. Professional Performance.

    The CZR Series is a range of passive loudspeakers offering high power handling and outstanding sonic performance in a portable, lightweight, yet rugged design. The CZR is ideal for a range of live performance and installed sound environments— from live bands at outdoor festivals to DJ’s in clubs—these loudspeakers deliver crystal clear, high-quality sound with impressive bass performance. For even more bottom end to round out your sound, adding CXS XLF Series passive subwoofers can extend your system’s low frequency performance dramatically down to a startling 29Hz for throbbing low frequency reproduction capability that’s sure to impress.

    The CZR10 is a 2-way loudspeaker offering high power handling and outstanding sonic performance in a portable, lightweight, yet rugged design. Its versatile, compact enclosure design makes the lightweight CZR10 ideal for range of live performance and installed sound environments—from live bands at outdoor festivals to DJ’s in clubs—these loudspeakers deliver crystal clear, high-quality sound with impressive low frequency performance.

    • 2-way loudspeaker with a 2” HF and a 10" LF
    • Features Yamaha's own Wide Dispersion CD Waveguide Horn
    • High power 700W(PGM) power handling and Bi-amp capable
    • Floor monitoring setting
    • Lightweight yet very durable plywood cabinet with premium graded Polyurea coating
    • Dual-angle pole socket
    • Optional speaker cover (SPCVR-DZR10)
    • Rotatable horn and variety of U-bracket options (UB-DZR10H/V) for rigging allow for very flexible setup and speaker placement



    In the Box:

    Yamaha CZR10 700W 2-Way 10" Passive Loudspeaker (Black)

  • Configuration Passive 2-Way

    Enclosure Type Bass-Reflex Loudspeaker

    Total Power Capacity Passive:
    350 W RMS
    700 W Program
    1400 W Peak

    Bi-Amp / LF:
    350 W RMS
    700 W Program
    1400 W Peak

    Bi-Amp / HF:
    50 W RMS
    100 W Program
    200 W Peak

    System Impedance 8 Ohms (Passive)

    LF:
    8 Ohms (Bi-Amp)

    HF:
    16 Ohms (Bi-Amp)

    Drivers
    HF Driver 1 x Rotatable Horn Titanium Compression Driver with 1" / 25.4 mm Throat

    HF Voice Coil 2" / 50.8 mm

    LF Driver 1 x 10" / 25.4 cm Woofer

    LF Voice Coil 3" / 76.2 mm

    Magnet HF:
    Neodymium

    LF:
    Neodymium


    Performance
    Frequency Range 43 Hz to 20 kHz -10 dB

    Maximum SPL
    127 dB SPL (Peak, Passive)
    127 dB SPL (LF, Peak, Bi-Amp)
    131 dB SPL (HF, Peak, Bi-Amp)

    Coverage Angle
    90° H x 60° V (Rotatable Horn)
    60° H x 90° V (Monitor)

    Speaker Sensitivity Passive:
    95 dB SPL

    Bi-Amp/LF:
    95 dB

    Bi-Amp/HF:
    108 dB SPL


    Connectivity
    Audio I/O 2 x speakON NL4


    Signal Processing
    Crossover 2.5 kHz


    Physical
    Mounting
    2 x 1.4" / 35 mm Pole Socket (Dual Angle, Top)
    8 x M10 Fly Point
    2 x M8 Fly Point

    Monitor Angle 50°

    Handles 1 x Each Side

    Construction Material Plywood

    Dimensions 12.4 x 21.1 x 13.6" / 315 x 537 x 345 mm

    Weight 30.9 lb / 14 kg
