Equip your studio with pro monitoring features for a song.
Manage multiple audio sources and sets of monitor speakers, track using illegally loud headphone amplifiers, and talk back to your drummer—all from your desktop.
Consider your sources.
Switch quickly and easily between up to four audio sources with a selection of input types.
Manage Your Destinations.
Audition your music with your choice of three stereo pairs of speaker outputs, each with separate level control. Four screaming-loud headphone outs and a talkback mic ensure your musicians hear every note—and your instructions—clearly.
Customize your system for the way you work.
There’s more to managing a monitoring system than I/O, level controls, and talkback. The Monitor Station V2 offers powerful options that allow you to configure it for the way you like to work.
Take control of your monitor system.
With its ergonomic, intuitive layout; extensive features, and I/O; and PreSonus’ famed sound quality, Monitor Station V2 provides a versatile, convenient, and affordable solution for managing your studio monitoring system from your desktop. So sashay down to your PreSonus dealer and take control of your monitoring system the way the professionals do!In the Box:
PreSonus Monitor Station V2 Desktop Studio Control Center
Power AdapterInputs
Microphone
Gain Range:
+15 to +55 dB
Type:
Electret condenserSensitivity:
-42 dBStereo Input
Type:
1/4” TRS Active Balanced
Input Impedance:
10 kΩ (balanced)S/N Ratio:
(1 kHz @ +10 dBu, unity gain) >105 dBTHD+N:
(unwtd, 1 kHz @ 0 dBu output, unity gain)Frequency Response:
(±0.5 dB) 10 Hz to 65 kHzNoise Floor:
(20 Hz to 20 kHz, 150Ω input termination) -96 dBuMaximum Input Level:
(minimum gain, 1 kHz @ 0.5% THD+N) +22 dBuAUX Inputs
Type:
RCA active unbalanced
Input Impedance:
47.5 kΩS/N Ratio:
(1 kHz @ 0 dBu, Unity Gain) >115 dBTHD+N:
(unwtd, 1 kHz @ 0 dBu Output, Unity Gain)Frequency Response:
(±0.5 dB) 10 Hz to 50 kHzGain Range:
80 dB to +10 dBS/PDIF
Type:
RCA 75Ω coax
Dynamic Range:
113 dBTHD+N:
0.0025% (1 kHz @ -1 dBFS)Maximum Output:
at 0 dBFS +18 dBuSample Rates:
44.1, 48, 88.2, 96 kHzInput Meters
Type:
Dual 8-segment LED w/peak hold
Sensitivity Range:
-24 dB to 0 dBOutputs
Analog Outputs
Type:
1/4" TRS active balanced
Output Impedance:
51Ω (balanced)THD+N:
(unwtd, 1 kHz @ 0 dBu, unity gain)Frequency Response:
(±0.5 dB) 10 Hz to 50 kHzSpeaker Out
Trim Range:
-80 dB to 0 dB
Main Level Range:
-80 dB to 0 dBDim Attenuation Range:
-30 dB to -6dBCue
Cue Level Range:
-80 dB to 0 dB
Dim Attenuation:
(talkback activated) -20 dBHeadphone Outputs
Type:
1/4” TRS active stereo
Maximum Output:
(60Ω load) 150 mW / channelFrequency Response:
(±1.0 dB) 10 Hz to 50 kHzPower
Power Supply Type:
External DC transformer/internal line
Input Connector Type:
Barrel, 5.5 mm outside diameter, 2.1 mm inside diameterMonitor Station Input Voltage Range:
18 VDCPower Requirements:
(continuous) 10WPhysical:
2.5 x 8.5 x 9.0" (63.5 x 216.0 x 228.6 mm)
Weight:
6 lb (4.54 kg)
