Magewell Pro Convert for NDI to HDMI Decoder

magewell_64100_pro_convert_ndi_to_1517124_1741300376

S$ 637.50
(S$ 637.50 excl GST)

Not shipping to UNITED STATES OF AMERICA Want this delivered today? Find out more

Add to cart Add to wishlist

What?! Seen it cheaper somewhere?
Please tell us so we can try to match it!

Convert full NDI stream and other IP streams

Key Features:

Convert NDI Signal to HDMI Stream
Embedded Audio Supported
Up to DCI 4K NDI Input
Up to 2K60p or 4K15 HDMI Output

Use the Pro Convert NDI to HDMI Decoder from Magewell to convert an NDI stream with embedded audio to an HDMI signal output. It supports resolutions up to 4K60 over NDI input, and decodes NDI streams up to 2K60 and DCI 4K at 15 fps over HDMI output. The device can be powered via an included USB power adapter or over PoE using the RJ45 port.
A companion Web UI allows web configuration from a wide variety of web browsers, such as the device name, source name, NDI and EDID identifiers, and other settings. It features a 1/4"-20 thread for camera mounting and can be used in the studio or in the field thanks to a compact and durable design.
HDMI Specific Features
- Decode NDI, RTSP, HTTP, RTMP Pull/Push, and TS streams over UDP/SRT/RTP
  H.264 and H.265 format support
- Customized EDID support
- Up to 2K60 NDI input stream
- Up to DCI 4K HDMI output signals
- NDI decoder converts from 2K to 2K60 output; from 4K to 4K15 output
- 96 kHz, 16-bit, 8-channel audio streams
Supported Web Browsers
- Microsoft Internet Explorer 11
- Microsoft Edge
- Mozilla Firefox version 61 and above
- Google Chrome version 49 and above
- Apple Safari 11.1 and above
- Opera 55.0.2994.44 and above
Video Decoding Features
- 150-megapixel decoding
- Tally indicators
- Audio meter and audiometer scale
- Audio gain, sample rate, and channel settings
- Center marker
- Safe area
- Video scaling, frame rate, and aspect ratio conversion
- Video color format conversion with YUV BT.601, YUV BT.709 color format support
- Auto or manual selection of input color format
- Remote control passthrough for PTZ camera
- Video frame rate conversion
- Video vertical and mirror flip
Supported Software
- Pro Convert encoder
- Magewell Bridge for NDI
- NewTek Connect
- NDI Studio Monitor
- OBS Studio
- vMix
- VLC
- IP Camera
- Haivision
In the Box
Magewell Pro Convert NDI to HDMI Decoder
Power Adapter
L-Bracket
USB Cable
Limited 1-Year Warranty

Specifications

Supported Web Browser (tested)
Microsoft Internet Explorer 11
Microsoft Edge
Mozilla Firefox version 61 and above
Google Chrome version 49 and above
Apple Safari 11.1 and above
Opera 55.0.2994.44 and above

Output Interfaces
HDMI
DVI-D 1.0
HDMI 1.4
HDMI 2.0

Storage Interface
SD Card (functions to be developed)

Screw Mounting Hole
¼–20 mounting hole

Network Interfaces
10/100/1000Mbps Ethernet
IEEE 802.3af PoE

USB Interface
USB2.0 Type B
5V/2.1A power supply
USB RNDIS/ECM
USB3.0 Type A
Support connecting peripherals (keyboard and/or mouse) to customize the video and audio settings

Control Buttons
MENU: press to display the menu, or cycle through the options
SELECT: press to display the menu, enter current option, or confirm the selection

HDMI Output Features
Support up to 4096x2160 60fps HDMI output
Support 96KHz 16bits 8-channel audio streams
Support delivering videos at the preferred video format according to the EDID of the connected monitor

Stream Decoding Features
Support decoding streams of NDI, RTSP, HTTP, RTMP Pull/Push and TS over UDP/SRT/RTP
Support decoding videos in H.264 and H.265 format
Support up to 150M pixels/s decoding
When receiving 2K NDI® stream, the device could decode and convert it to 2K 60fps
When receiving 4K NDI® stream, the device could decode and convert it to 4K 15fps
Support modifying configurations using the Web UI or the Options menu
Setting Video OSD composition, including
Source name & resolution
Tally indicators
Audio meter
Audio meter scale
Center cross
Safe area
Video scaling, frame rate and aspect ratio conversion
Video color format conversion
Auto or manual selection of input color format
Support YUV BT.601, YUV BT.709 color formats
Video vertical and mirror flip
Remote controlling the PTZ device connected to the video source
Setting audio gain, sample rate and channels

Device Name
Support setting the device name shown in the system using Web UI. By default, the device name is ‘Pro Convert’.
Support setting board-index, from 0 to F, through the on-board rotary switch

Firmware Upgrade
Support manual update using Web UI

LED Indicator
Power LED status indicator
On: power connected
Off: power unconnected
Decode LED status indicator
On: decoding in progress
Blinks: decoding error
Off: source unselected

Form Factor
100.9mm (L) x 60.2mm (W) x 23.3mm (H)

Accessories
USB 2.0 A to B Cable
5V/2.1A power adaptor
L-bracket

Power Consumption
5V max current: ~1.1A
Max power consumption: ~5W

Working Environment
Operating temperature: 0 to 45 deg C
Storage temperature: –20 to 70 deg C
Relative Humidity: 5% to 90% non-condensing
